Product Details
Place of Origin: changzhou
Certification: CE and ISO9001
Model Number: LPG
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD15,000 - USD1500,000
Packaging Details: exporting package
Delivery Time: 30-90
Payment Terms: T/T in advance
Supply Ability: 1-10sets/month
Heating Method: |
Electricity/ Steam/ Conduction Oil, Etc |
Production Material: |
Contact Parts SS304, 316L |
Application: |
Chemicals Processing, Plastics Processing, Food Processing |
Type: |
Atomizer Spray Dryer |
Dried Powder Collecting: |
≥ 95 |
Service: |
Engineers Available To Service Machinery Overseas |
Spraying Desc Diameter: |
50-340mm |
Raw Material: |
Liquid Material |
Input: |
5-10000kg/h |
Inlet Temp: |
Around 160 |
Heating Method: |
Electricity/ Steam/ Conduction Oil, Etc |
Production Material: |
Contact Parts SS304, 316L |
Application: |
Chemicals Processing, Plastics Processing, Food Processing |
Type: |
Atomizer Spray Dryer |
Dried Powder Collecting: |
≥ 95 |
Service: |
Engineers Available To Service Machinery Overseas |
Spraying Desc Diameter: |
50-340mm |
Raw Material: |
Liquid Material |
Input: |
5-10000kg/h |
Inlet Temp: |
Around 160 |
To reduce stickiness in acid whey powder during spray drying, common additives include:
Silica: Helps absorb moisture and prevent clumping.
Maltodextrin: Provides bulk and reduces stickiness.
Modified Starches: Improve flow properties.
Lecithin: Enhances powder flow and reduces clumping.
These additives help improve the drying process and enhance the final product's stability and usability.
Process Overview
| Model | PLG | |||||
| 5 | 25 | 50 | 100 | 150 | 200-2000 | |
| inlet temperatyre ℃ | 140-350 automatically controlled | |||||
| outlet temperatyre ℃ | 80-90 | |||||
| Max water evaporation capacity kg/h | 5 | 25 | 50 | 100 | 150 | 200-2000 |
| centrifugal spraying nozzle transmission mode | compressed air transmission | mechaical transmission | ||||
| rotation speed (r.p.m) | 25000 | 18000 | 18000 | 18000 | 15000 | 8000-15000 |
| spraying desc diameter (mm) | 50 | 100 | 120 | 140 | 150 | 180-340 |
| max electric heating power (kw) | 9 | 36 | 63 | 81 | 99 | settled by customer |
| overall dimensions | 1.8*0.93*2.2 | 3*2.7*4.26 | 3.7*3.2*5.1 | 4.6*4.2*6 | 5.5*4.5*7 | depends on tryer |
| dried powder collection | ≥95 | ≥95 | ≥95 | ≥95 | ≥95 | ≥95 |
Temperature Control:
Inlet Temperature: Typically around 160-200°C (320-392°F).
Outlet Temperature: Usually around 70-90°C (158-194°F).
Prevents degradation of proteins and maintains quality.
Stickiness:
Acid whey can be sticky; additives or optimized drying conditions may be needed.
Hygiene:
Ensure rigorous cleaning to prevent contamination.
Benefits
Shelf Life: Extends the usability of whey.
Versatility: Powder can be used in various food applications.
Careful monitoring and control of the drying parameters are crucial to achieving high-quality acid whey powder.
