Product Details
Place of Origin: changzhou
Model Number: KJG hollow blade dryer
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD20,000-200,000
Packaging Details: EXPROTING
Delivery Time: 30-90 DAYS
Payment Terms: TT
Supply Ability: 10SET/MONTH
Effective Volume: |
0.06-9.46m³ |
Advantage: |
Low Price， Good Quality |
Size: |
Customized |
After-sales Service: |
Provided |
Structure: |
Wedge-shaped Hollow Paddle |
Warranty: |
1 Year |
OEM Service: |
Available |
Heating Source: |
Steam, Hot Water, Electricity, Etc |
Effective Volume: |
0.06-9.46m³ |
Advantage: |
Low Price， Good Quality |
Size: |
Customized |
After-sales Service: |
Provided |
Structure: |
Wedge-shaped Hollow Paddle |
Warranty: |
1 Year |
OEM Service: |
Available |
Heating Source: |
Steam, Hot Water, Electricity, Etc |
Hollow Paddle Dryer is a vacuum paddle dryer with a wedge-shaped hollow paddle structure. It is designed for drying materials in the pharmaceutical, chemical, and food industries. It features a heating source with steam, hot water, electricity and other options, a customized pressure, an effective volume ranging from 0.06 to 9.46 m³, and a one-year warranty. This Paddle_Hollow_Dryer is suitable for efficient drying of granular, powder, and paste materials. It is also easy to operate, maintain, and clean, providing a reliable Paddle_Dryer_Hollow solution for many industrial applications.
| Parameter | Details |
|---|---|
| Material | SS304 316L |
| Heating source | Steam, Hot Water, Electricity, Etc |
| Weight | Customized |
| Advantage | Low Price, Good Quality |
| After-sales Service | Provided |
| Size | Customized |
| Power | 2.2-95KW |
| Effective volume | 0.06-9.46m³ |
| Pressure | Customized |
| Heat transfer area | 2.7-110 ㎡ |
| Model | KJG-2.7 | KJG-24 | KJG-52 | KJG-81 | KJG-110 |
| Heat transfer area | 2.7 | 24 | 52 | 81 | 110 |
| effective volume | 0.06 | 1.53 | 3.96 | 6.43 | 9.46 |
| revolution | 15-30 | 10-20 | 10-20 | 5-15 | 5-10 |
| power | 2.2 | 11 | 30 | 55 | 95 |
| width of dryer body | 306 | 1118 | 1474 | 1828 | 2210 |
| total width | 736 | 1474 | 1854 | 2286 | 2668 |
| length of dryer body | 1956 | 3454 | 5258 | 6020 | 6122 |
| total length | 2972 | 6147 | 8306 | 9678 | 9880 |
| distance between feeding and disharging | 1752 | 3150 | 4954 | 5562 | 5664 |
| height in center | 380 | 1066 | 1220 | 1220 | |
| total height | 762 | 2032 | 2464 | 2668 | |
| steam inlet | (2) 3/4 | (2) 1 | (2) 11/2 | (2) 11/2 | (2) 2 |
| water outlet | (2) 3/4 | (2) 1 | (2) 11/2 | (2) 11/2 |
(2) 2
|
The Hollow Paddle Dryer, model number KJG hollow blade dryer, is a vacuum paddle dryer produced in Changzhou. With a minimum order quantity of 1 and price ranging from USD20,000 to 200,000, the dryer comes with EXPROTING packaging and a delivery time of 30-90 days. Payment terms are TT and the supply ability is 10SET/MONTH. The effective volume is 0.06-9.46m³ and the structure is Wedge-shaped Hollow Paddle, with customized weight and size. After-sales service is provided.
Hollow Paddle Dryer
Model Number: KJG hollow blade dryer
Place of Origin: changzhou
Certification:
Minimum Order Quantity: 1
Price: USD20,000-200,000
Packaging Details: EXPROTING
Delivery Time: 30-90 DAYS
Payment Terms: TT
Supply Ability: 10SET/MONTH
After-sales Service: Provided
OEM Service: Available
Material: SS304 316L
Weight: Customized
revolution: Customized
Special Features: Vacuum Blade Dryer, Hollow Paddle Dryer, Blade Hollow Drying
