Home > PRODUCTS > Fluid Bed Granulator > 500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine

500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine

Product Details

Place of Origin: China

Brand Name: JingSu ShengMan

Certification: CE and ISO9001

Model Number: FLG

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: USD20000-USD300000

Packaging Details: Plywood Cases

Delivery Time: 60-90days

Payment Terms: L/C, T/T

Supply Ability: 10sets

Get Best Price
High Light:

1500L Fluid Bed Granulator

,

500KG/Batch Fluid Bed Granulator

,

500KG/Batch Plastic Recycling Granulator Machine

Condition:
New
Warranty:
1 Year
Voltage:
Customized
Machine Type:
Granulator
Heating System:
Steam,Electronic,oil
Standard:
GMP
Material:
Stainless Steel
Power Of Fan:
5.5-18.5 Kw
Dimension:
Requirement From Customer
Application:
Pharmaceutical, Food, Chemical
Condition:
New
Warranty:
1 Year
Voltage:
Customized
Machine Type:
Granulator
Heating System:
Steam,Electronic,oil
Standard:
GMP
Material:
Stainless Steel
Power Of Fan:
5.5-18.5 Kw
Dimension:
Requirement From Customer
Application:
Pharmaceutical, Food, Chemical
500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine

FLG solid preparation plastic recycling granulator machine or Wet granulator For Pharmacy in Latin America





DESCRIPTION



1. PLC intelligent control, high degree of automation, easy operation and maintenance.

2. Fully automatic sealing type feeding, unloading system, pipeline connection, clamp type connection, no dead angle, easy to disassemble, easy to clean.
3. The equipment is designed according to the 2bar pressure standard, and the components of the whole machine have a good grounding method.
4. Made of full stainless steel, the part in contact with the material is made of stainless steel.



500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine 0





Technical Parameters



Machine Name
Specification Item
FL-120
FL-200
FL-300
FL-500

Capacity
KG/batch



120
200
300
500





Fluid-Bed
granulator
dryer
Container
L
420
670
1000
1500
Dia
mm
1200
1400
1600
1800
Power of fan
KW
18.5
22
30
45
Power of supply liquid motor
Kw
0.37
Pressure of steam
Mpa
0.4-0.6
Consumption of steam
KG/h
140
180
310
400
Pressure of compressed air
Mpa
0.4-0.6
Consumption of compressed air
M3/min
0.9
1.1
1.1
1.5
Working temperature
Normal temperature-120℃ could adjust



High Efficient Wet Granulator
Model

HLSG100
HLSG200
HLSG300
Bowl Volume Litre
L
100
200
300
Max Material Charge Amount kg/batch
KG
40
80
100-130
Mixing Power
kw
7.5
13
22
Mixing Speed r/min
r/min
25-500
25-500
10-150
Net weight
kg
500
850
1200

Integral Unit
Model
(mm) Overall Dimensions(LxHxW)
FL-120/HLSG-200
4000x2000x4500
FL-200/HLSG-300
5000x2500x5000
500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine 1




Scope of application:
1. Tablets, granules (granules), capsules.
2. Low sugar, no sugar, small dose of particles.
3. Slow release granules.
4. Instant food, drink granules.
5. Chemical particle preparation.



500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine 2


Pre-service:
As a good and rich experience supplier, we should offer customer the best quality and best price of the machine.
1. Introduce the suitable product to the customer in detail, answer the question raised by customer carefully.
2. Make the suitabe project as the customer requirement and make sure the machine is suitable for the material.

Sale service:
(1). Ensure product with high quality and pre-commissioning before delivery. (
2). Delivery on time. (3). Provide full set of documents as customer’s requirements.



After-sale service:
Provide considerate services to minimize clients’ worries.

1. Assist clients to prepare for the first construction scheme.
2. Install and debug the equipment.
3. Train the first-line operators.
4. Examine the equipment.
5. Take initiative to eliminate the troubles rapidly.
6. Provide technical support.
7. Establish long-term and friendly relationship.



Service commitment:
1. Provide clients one-year warranty to make sure the machine work well.

2. We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely.

3. Send every client a preferential quotation.



500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine 3

500KG/batch 1500L Fluid Bed Granulator Solid Plastic Recycling Granulator Machine 4
